EXTREME XA Series Air Shrink Wrap System


nVenia’s ARPAC Brand EXTREME XA models excel in a wide variety of applications. These pneumatically driven wrapping systems are designed to increase productivity, reduce wear and tear on parts, and eliminate the waste of time and energy by using a continuous motion design with a smooth, fast, and unbroken flow. With its superior design, the XA models are more reliable, require less maintenance, use less film and energy, and provide superior film tension for a better more consistent package. Additionally, the XA continuous motion wrappers will typically require 2-4” less film width than automatic L-sealers, intermittent motion wrappers, or any wrapper where the film path runs under the infeed conveyor

Are you interested in this product?
We are here to help.

Contact Us

Featured Video

Features

Features

  • Heavy- duty construction for high durability and 24/7 operation
  • Seal bars with multi-zone heater design for strong consistent seals
  • Direct drive motors eliminate chains, sprockets, tensioners and the need for lubrication or any maintenance in those areas
  • Easy clean side seal does not use any back up wheels, rubber rollers or separate cutting devices that require maintenance or replacement
  • Color touchscreen on swivel allows two sided operation
  • Tool-less changeover decreases maintenance
  • Large gull wing doors allow easy access to major machine assemblies for periodic  cleaning and inspection
  • Powered scrap winder with dancer bar control and film break detect

Standard Specs

Specifications

  • Speed: 75 cycles per minute
  • Electrical power requirements: 240 VAC, 3 Ph, 60 Hz
  • Air Requirements: 5 SCFM at 80 psi

Options

  • Multiple frame and cross seal sizes
  • Standard or custom infeeds for almost any application
  • Powered product bypass
  • Single or dual roll film centerfolders
  • Stainless steel construction

Package Size Range

  • XA (Side Seal) – 18″ W x 8″ H
  • XAT (Top Seal) – 8″ W x 12″ H
  • XAL (Lap Seal) – 18″ W x 8″ H
    *All models are capable of infinite length.

Film

  • Max. roll diameter: 16”
  • 30 to 75 gauge polyolefin or 1 to 3 mil low density polyethylene
  • Type: LDPE, polyolefin
  • Other specifications: up to 52″ flat or 25″ centerfold
